SP300 Single Channel Human Syringe Pump
It supports manual and automatic bolus functions. Featuring an anti‑bolus system and DPS occlusion pressure display, it ensures safe infusion. Event records can be stored, reviewed and exported. It allows vertical and horizontal mounting. Its built‑in battery offers 8‑hour continuous operation. Compact and weighing around 2.5 kg, it delivers infusion volume from 0.1‑999.9 ml in 0.1 ml increments, ideal for accurate clinical medication delivery.
SP300 Syringe Pump
High‑Precision Clinical Infusion Solution for Patient‑Centered Care
Product Overview
Manufactured by Changsha Deepmed Medical, the SP300 Syringe Pump is a compact, high‑precision clinical infusion device for safe and accurate drug delivery across hospital wards, ICU, operating rooms and emergency departments. Supporting mainstream standard syringes, it is equipped with multiple programmable infusion modes, comprehensive safety alarm mechanisms and complete data‑recording functions. Benefiting from flexible power supply and human‑centered operation, SP300 provides stable and reliable performance for critical patient care scenarios.
Core Features
Wide Syringe Compatibility
Compatible with standard 5 ml, 10 ml, 20 ml, 30 ml, 50 ml, 60 ml syringes for diverse clinical requirements.
High Infusion Accuracy
±2% accuracy under correct calibration. Flow rate: 0.1 ml/h‑2000.0 ml/h with fine‑step adjustment for micro‑infusion and rapid infusion.
Multiple Programmable Modes
Rate / Time / Dose / Drug Library / Sequential modes. Supports weight‑based dosage calculation for standardized medication.
DPS Occlusion Pressure Control
25‑level adjustable occlusion pressure from 20 kPa‑160 kPa, timely pipeline blockage detection for enhanced patient safety.
Bolus, Purge & KVO Functions
Programmable bolus rate & volume, auto/manual bolus available. Purge rate and KVO rate (0.0‑20.0 ml/h) fully adjustable.
Comprehensive Safety Alarms
Alarms for occlusion, empty syringe, low battery, plunger disengagement and more. 3‑level alarm volume; optional silent function.
Data Recording & Interfaces
Stores up to 5000 history events for review and download. USB interface; optional Wi‑Fi. 1‑10‑level adjustable screen brightness.
Reliable Multi‑source Power Supply
AC / DC power input plus built‑in 7.2V 2600mAh lithium battery, supporting 8‑hour continuous operation for patient transfer.
Technical Specifications
| Applicable Syringes | Standard 5 ml,10 ml,20 ml,30 ml,50 ml,60 ml |
| Infusion Accuracy | ±2% (correct calibration required) |
| Flow Rate Range | 0.1 ml/h‑2000.0 ml/h (0.1 ml/h or 1 ml/h step) |
| Total Volume Range | 0.1‑9999.9 ml (0.1 ml step) |
| Dose Mode | Volume:0.1‑999.9 ml; Drug Mass:0.1‑999.9 mg; Dose:0.001‑9999; Weight:0.1‑300 kg |
| DPS Occlusion Pressure | 20‑160 kPa, 25‑level programmable adjustable |
| Bolus Volume | 1.0‑50.0 ml (0.1 ml step) |
| KVO Rate | 0.0‑20.0 ml/h, programmable & adjustable |
| History Records | 5000 events, support review & download |
| Power Supply | AC 100‑240V, DC 12‑15V; Built‑in 7.2V 2600mAh Li‑ion battery, 8‑h continuous runtime |
| Protection Class | Class I, Type CF, IPX4 |
| Dimension / Net Weight | 240mm*150mm*117mm, 2.5kg |
| Packing Size / Gross Weight | 300mm*260mm*160mm, 3.0kg |
Application Scenarios
Ideal for ICU, operating rooms, emergency departments, general wards and special‑care units. Widely used for precise IV medication, anesthesia infusion, analgesia therapy and critical‑care drug administration.
Inquiry for SP300 Syringe Pump
Contact us for quotation, product brochures and technical support.
