Model No: VS2000
VS2000 7-INCH VITAL SIGNS MONITOR
The VS2000 7-inch Vital Signs Monitor is designed for use in special procedure labs,
emergency transport and other areas of hospitals or clinics.
The standard parameters include 5/3 leads electrocardiography(ECG),
non-invasive blood pressure (NlBP), pulse oximetry (SpO2), respiration rate (RR), and temperature (TEMP)
Optional parameters include ETCO2.
2 years warranty
emergency transport and other areas of hospitals or clinics.
The standard parameters include 5/3 leads electrocardiography(ECG),
non-invasive blood pressure (NlBP), pulse oximetry (SpO2), respiration rate (RR), and temperature (TEMP)
Optional parameters include ETCO2.
2 years warranty
minimum order :
1 unit
Supply Ability :
2000unit / Month
Stock Time :
3Day
Quantity :
Description
Enhancing Visibility in Patient Care
We are unwavering in our commitment to patient safety, and we understand that staffing shortages can make it challenging to monitor every patient as frequently as needed.
Now, with the VS2000 vital signs monitor, you can conduct more comprehensive and continuous monitoring from the ambulance to the emergency room.
Designed for clinical settings where continuous tracking or additional physiological parameters are essential, this device helps healthcare professionals overcome time and space constraints, stay informed of patient status in real time, and support well-informed decision-making in emergency and critical care.
Emergency Care, Unfaltering Monitoring
The VS2000 is a transport vital signs monitor, expertly designed for ambulance and emergency medical use.
It also supports an optional temperature gun for rapid and accurate temperature measurement, enhancing its versatility in diverse emergency scenarios.
Easy to Use
The intuitive user interface is designed for clarity and ease, drawing on the proven foundation of UTECH's market-leading vital signs monitors—perfected and trusted over 16 years.
It is equipped with a built-in handle for easy and rapid movement between emergency sites and vehicles, allowing medical staff to quickly carry and reposition the device during critical moments.
Central Monitoring Compatible
The VS2000 is equipped with advanced connectivity options, allowing it to be seamlessly integrated into a Central Monitoring System.
This enables the real-time wireless transmission of patient data, facilitating streamlined data management.
Features of Vital Signs Monitor
- 7 inch High definition TFT LCD screen (800 x 480).
- The dexterous handle makes it convenient for medical staff to carry.
- Connect with the central monitoring system for remote and wireless monitoring by Wifi.
- Built-in large-capacity rechargeable Lithium battery.
- A three-level audio & visual alarm allows medical personnel to detect in time.
- Provides easy access to critical information via a stand alone bedside monitor.
- Standard configuration: ECG + SpO2 + PR + RESP + NIBP + TEMP.
- Numbers and trend data are provided and clearly displayed in real-time.
- Stores 120 hours of trend data at one-second intervals for PC analysis and archiving.
- Offers multiple predefined layouts for one-tap switching.
- Based on a portable, lightweight design that enables easy transport.
- This patient monitor comes with a 24-month manufacturer's warranty.
Specifications
| Display |
| Screen size: 7-inch diagonal high-resolution Screen type: TFT Active Matrix LCD Resolution: 800 X 480 pixels |
| SpO2 |
| Range: 0-100% Functional Saturation Accuracy: ± 2% @ 70-100% (<70% unspecified) Pulse Rate Range: 30-250 bpm Pulse Rate Accuracy: ± 2 bpm or ± 2% |
| ECG |
| Lead Set: 3-lead, 5-lead, 12-lead HR range: 20-350 bpm Sweep Speed: 6.25 mm/s; 12.5 mm/s; 25mm/s; 50 mm/s |
| NIBP |
| Method: Oscillometric with step-down deflation SYS Range: Adult (25-290), Pediatric (25-240), Neonate (25-140) mmHg Measurement Time: 30s to 50s typical |
| TEMP |
| T1: Body surface temperature probe Range: 0℃ to 50℃ / 32℉ to 122 ℉ Accuracy: ± 0.2℃ T2: Infrared forehead thermometer (optional) Range: 32.0℃ to 43.0℃ Accuracy: ±0.2℃ within 35.0℃–42.0℃ |
| CO2 (Optional) |
| Mode of Sampling: Sidestream Measurement Range: 0 to 114 mmHg / 0 to 15% Response Time: <3s (@100mL/min) Sampling Rate: 100 Hz |
| Respiration |
| Range: 0 to 120 rpm Accuracy: ±1 rpm Lead: Lead Ⅱ |
| Environmental |
| Temperature: 0 to 50 ℃ (Operating) Humidity: 15% to 95% (Operation) Degree of Protection: IPX 1, drip proof |
| Power Requirement |
| AC Input: 100 to 240V a.c., 50/60 Hz Rechargeable battery: 11.1V, 4.4Ah |
Clinical Applications
Ambulance
Emergency Room (ER)
Clinic
```
